商品の詳細:
|
|
| 起源の場所: | 中国 |
|---|---|
| ブランド名: | Glawall |
| 証明: | SGS, ISO 9001,UL, CE |
| モデル番号: | 完全モジュール式二重ガラス壁 |
| ドキュメント: | 25mm.pdf |
|
お支払配送条件:
|
|
| 最小注文数量: | 10正方形のMaters |
| 価格: | US$80.00 10 - 99 square meters |
| パッケージの詳細: | 合板 |
| 受渡し時間: | 20〜25日 |
| 支払条件: | L/C、D/A、D/P、T/T、Western Union |
| 供給の能力: | 月に3000平方メートル |
|
詳細情報 |
|||
| アドバンテージ: | 競争力のある価格,良いサービス,高い専門性,品質保証 | Origiの場所: | 中国広東省 |
|---|---|---|---|
| 工場認定: | はい | 工場面積: | 20000平方メートル |
| 素材: | アルミフレーム,音響パネル | 防音: | 38-45db |
| パネルの厚さ: | 60, 90.108mm | ガラスタイプ: | 固いガラス |
| 換気: | 空気流通システム | 保証: | 2年 |
| ハイライト: | 90mm aluminum partition wall,double glass modular partition,aluminum frame partition system |
||
製品の説明
| Advantage | Competitive price, good service, high professional, quality guarantee |
| Place of Origin | Guangdong, China |
| Factory Certification | Yes |
| Factory Area | 20000 square meter |
| Material | Aluminum Frame, Acoustic Panels |
| Soundproofing | 38-45dB |
| Panel Thickness | 60, 90, 108mm |
| Glass Type | Strong tempered glass |
| Ventilation | Airflow System |
| Warranty | 2 Years |
| Feature | Benefit |
|---|---|
| Pre-Assembled Double Glass Panels | Complete 5+5mm glass panels with integrated frame - no on-site assembly |
| Plug-and-Play Channels | Simple installation with top/side/bottom aluminum tracks |
| Tool-Free Connection | Patented click-lock system secures panels without tools |
| Fast Installation | 2-person team can install 20m² in under 3 hours |
| 42dB Soundproof Rating | 10mm air gap effectively blocks office noise |
| Thermal Insulation | Reduces HVAC costs by maintaining stable temperatures |
| Step | Action |
|---|---|
| Step 1 | Install aluminum tracks (ceiling/floor/sides) using laser level |
| Step 2 | Slide pre-assembled glass units into steel keel - no heavy lifting required |
| Step 3 | Snap decorative covers over joints for perfect alignment |
| Feature | Specification |
|---|---|
| Frame | 90mm powder-coated aluminum (20+ RAL colors) |
| Glass | 5+5mm tempered (clear/frosted/tinted options) |
| Acoustics | 42dB Rw (upgradable to 48dB with laminate) |
| Fire Rating | EI30-EI60 available |
| Max Height | 4m without additional support |
| For Contractors | For Clients |
|---|---|
| 70% faster installs = more projects per year | Immediate usability - No waiting for paint/drywall to cure |
| 50% less labor cost vs traditional systems | Adaptable layouts - Reconfigure teams without construction |
| No construction waste - LEED points achievable | Premium aesthetics - Sleek, modern appearance |
